INVT Goodrive3000 Series Operation Manual page 136

Goodrive3000 series medium voltage VFD
Function code
P18.02
P18.03
P18.04
P18.05
P18.06
P18.07
P18.08
P18.09
P18.10
P18.11
P18.12
P18.13
P18.14
P18.15
P18.16
P18.17
P18.18
P18.19
P18.20
P18.21
Name
Encoder Z pulse count
0–65535
value
Count value of resolver 0–65535
Resolver angle 0–359.99
Magnetic pole angle 0–359.99
Motor temperature
-200.0–200.0℃
display
Frequency reference -100.00–100.0% (of the max. VFD
sent by master frequency)
Frequency command -300.00–300.0% (of the motor rated
received by slave current)
Speed loop output sent -100.00–100.0% (of the max. VFD
by master frequency)
Torque command -300.00–300.0% (of the motor rated
received by slave current)
Voltage of upper half
0–65535
bus
Voltage of lower half
0–65535
bus
Software version
1.00–655.35
(FPGA)
Reserved/Max.
midpoint voltage Reserved/0–512
balance compensation
Reserved/
Reserved/Midpoint 0: bang-bang control
voltage balance mode 1: P control
2: PI control
Max. midpoint voltage
balance
compensation/Midpoint 0–512/0–500
voltage balance
algorithm Kp
Midpoint voltage 0: bang-bang control
balance mode/Midpoint 1: P control
voltage balance 2: PI control
algorithm Ki /0–10
Midpoint voltage
balance algorithm 0–5000/
Kp/Grid voltage and 0: Grid voltage calculation
main contactor 1: Set by P20.14
condition selection
Midpoint voltage
balance algorithm
0–10/0–65535
Ki/Input grid voltage
balance degree
Max. bus voltage
0.0–6550.0V
recorded by the system
Max. upper bus voltage
0.0–3275.0V
recorded by the system
Description
-130-
Goodrive3000 inverter
Setting range Default
0–65535 0
0–65535 0
0–359.99 0
0–359.99 0
-200.0–
0.0° C
200.0° C
-100.00–100.0 0
-300.00–
0
300.00
-100.00–100.0 0
-300.00–
0
300.00
0–65535
0–65535
1.00–655.35
Reserved/ 0– Reserved
512 /400
Reserved
Reserved/0–2
/1
0–512/0–500 100/200
0–2/0–10 0/6
0–5000/0–1 400/0
0–10/0–65535 6/0
0.0–6550.0 0.0
0.0–3275.0 0.0
