Goodrive3000 series medium voltage VFD
Function
code
P06.24 AO2 output filter time
P07 group––Human-machine interface
P07.00 User password
P07.01 Parameter copy
QUICK/JOG key function
P07.02
P07.03
Stop function validity of
P07.04
Parameter selection in
P07.05
rectification state
P07.06
P07.07 Factory bar code 1
P07.08 Factory bar code 2
P07.09 Factory bar code 3
P07.10 Factory bar code 4
P07.11 Factory bar code 5
P07.12 Factory bar code 6
P07.13–
P07.16
Name
0.000–10.000s
0–65535
0: No operation
1: Upload parameters from the local
address to the keypad
2: Download parameters from the
keypad to the local address
0: No function
1: Switch between states
selection 2: (Reserved)
3: Quick debugging
Reserved
0: Valid only for keypad control
1: Valid both for keypad and terminal
control
STOP/RST 2: Valid both for keypad and
communication control
3: Valid for all control modes
0x0000–0xFFFF
Bit 0: DC bus voltage (V)
Bit 1: Grid frequency (Hz)
Bit 2: Input voltage (V)
Bit 3: Input current (A)
Bit 4: Input power factor
Bit 5: Active current component (%)
Bit 6: Reactive current component
(%) (% blinking)
Bit 7: Input terminal status
Bit 8: Output terminal status
Bit 9: AI1 (V)
Bit 10: AI2 (V) (V blinking)
Bit 11: AI3 (V)
Bit 12: Input apparent power (kVA)
Bit 13: Input active power (kW)
Bit 14: Input reactive power (kVar)
Bit 15: Reserved
Reserved
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
Reserved
Description
-52-
Goodrive3000 rectifier
Setting
Default Modify
range
0.000–
0.000s
10.000
0–65535 0
0–2 0
0–3 0
0–3 3
0x0000–
0x000F
0xFFFF
○
○
◎
○
○
○
●
●
●
●
●
●
