INVT Goodrive3000 Series Operation Manual page 153

Goodrive3000 series medium voltage VFD
Function
code
Setting channel of B
P00.07
frequency command
Reference object of B
P00.08
frequency command
Combination mode of setting
P00.09
Frequency set through
P00.10
P00.11
P00.12
P00.13
P00.14
P00.15 Motor parameter autotuning
P00.16 AVR function selection
Name
source
keypad
ACC time 1
DEC time 1
Running direction
Carrier frequency
Description
6: Multi-step speed running
7: PID control
8: MODBUS communication
9: PROFIBUS/CANopen
communication
10: Ethernet communication
11: Reserved
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
5: Simple PLC program
6: Multi-step speed running
7: PID control
8: MODBUS communication
9: PROFIBUS/CANopen
communication
10: Ethernet communication
11: Reserved
0: Max. output frequency
1: A frequency command
0: A
1: B
2: (A+B)
3: (A-B)
4: Max(A, B)
5: Min(A, B)
0.00 Hz–P00.03 (Max. output
frequency)
0.0–3600.0s
0.0–3600.0s
0: Run at the default direction.
1: Run at the opposite direction.
2: Disable reverse running
1.0–4.0kHz
0: No operation
1: Rotary autotuning
2: Static autotuning
3: Static autotuning 2 (partial
autotuning, the first 3 parameters
only)
0: Invalid
1: Valid during the whole
procedure
-147-
Goodrive3000 inverter
Setting
Default Modify
range
0–11 1
0–1 0
0–5 0
0.00–P00.03 50.00Hz
Model
0.0–3600.0
depended
Model
0.0–3600.0
depended
0–2 0
Model
1.0–4.0
depended
0–3 0
0–1 1
○
○
○
○
○
○
○
○
◎
○
