Goodrive3000 series medium voltage VFD

3.1 Unpacking inspection

• Package inspection
Please check the package carefully before unpacking. Check whether there is any damage or unpacking clue.
In addition, check whether the package is soaked or moistened. If any problem is found, contact the local dealer or INVT
office.
• Unpacking inspection
Please check as follows after unpacking:
The appearance of the product is good, and there are no related accessories falling off; the product manual, keypad and
other accessories are complete; there is no other foreign matter except foam in the package. If any problem is found,
contact the local dealer or INVT office.

3.2 Environment requirements

3.2.1 Storage environment

(1) The temporary storage environment must meet the requirements in the following table.
Item
Transport and storage
temperature
Relative humidity
Air
(2) Permanent storage environment
If the VFD cannot be used at present due to project change or other reasons after it is bought, store it by referring to the
following instructions according to the specific situations.
The environment requirements for temporary storage must be met first of all. If the storage period exceeds 3 months, the
environment temperature must be controlled below 30℃. This is mainly because the performance of the electrolytic
capacitors inside the VFD will degrade if it is not powered.
Store the VFD with care to avoid intrusion of moisture. You can consider putting desiccant in the packing box of the VFD
to control the humidity inside the box below 70%.
If the VFD is installed inside a control cabinet or other equipment, especially on a construction site, it will be in a moist and
dusty condition. If it will not be used for a long period, we recommend you to remove it and store in a place in good
conditions.
The performances of the electrolytic capacitor will degrade if not used for a long period. When the VFD is stored for a long
period of time, we recommend you to power on it at least once every year.

3.2.2 Running environment

Item
Running
environment
temperature
Relative humidity 5%–95%
Air

3 Installation guidance

Table 3-1 Temporary storage environment requirements
-40° C–70° C
5%–95%. Even if the humidity meets the requirement,
avoid the situations which can cause condensation and
icing due to sudden temperature change.
Store the VFD in a place free of dust, direct sunshine, flammable gas, oil
pollution, steam and vibration.
Table 3-2 Operating environment requirements
-10° C – +50° C. Derate 3% for every increase of 1° C when the temperature is above
40° C.
Store the VFD in a place free of dust, direct sunshine, flammable gas, oil pollution,
steam and vibration.
Specifications
Specifications
-13-
Installation guidance
No condensation or
icing, which may be
caused by sudden
temperature change
