INVT Goodrive3000 Series Operation Manual page 177

Goodrive3000 series medium voltage VFD
Function
code
Frequency increment time of
P08.45
Frequency increment time of
P08.46
the DOWN terminal
Action selection at power-off
P08.47
during frequency setting
P08.48–
P08.49
Magnetic flux braking
P08.50
P08.51 VFD input power factor
P09 group–– PID control
P09.00 PID reference source
P09.01
Name
the UP terminal
Reserved
coefficient
PID digital setting
Description
for stop
0: Setting is valid.
1: Valid during running, cleared
after stop
2: Valid during running, cleared
after a stop command is received
0.01–50.00s
0.01–50.00s
0x000–0x111
Ones place: Action selection at
power-off during frequency
adjusting through digitals.
0: Save the setting at power-off.
1: Clear the setting at power-off.
Tens place: Action selection at
power-off during frequency
adjusting through MODBUS
communication
0: Save the setting at power-off.
1: Clear the setting at power-off.
Hundreds place: Action selection
at power-off during frequency
adjusting through
communication methods
0: Save the setting at power-off.
1: Clear the setting at power-off.
0: Invalid
100–150: A larger coefficient
indicates stronger braking.
0.00–1.00
0: Set by P09.01
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
5: Multi-step running
6: MODBUS communication
7: PROFIBUS/CANopen
communication
8: Ethernet communication
9: Reserved
-100.0%–100.0%
-171-
Goodrive3000 inverter
Setting
Default Modify
range
0.01–50.00 0.50s
0.01–50.00 0.50s
0x000–
0x000
0x111
other
0–150
0.00–1.00 0.56
0–9
-100.0–
0.0%
100.0
○
○
○
○
0
○
○
0
○
