P03 Group--Vector Control - INVT Goodrive3000 Series Operation Manual

Goodrive3000 series medium voltage VFD
variable-frequency motor is not impacted by the rotation speed, it is not necessary to adjust the protection value at low
speed running.
Function
code
P02.27
coefficient of motor 1
Motor overload multiple M=lout/(In*K)
In: motor rated current, Iout: VFD output current, K: motor overload protection coefficient
Function
code
P02.28
Function
code
P02.29
The function code is used to select the parameter display mode of motor 1.
0: Display by motor type. In this mode, only parameters related to the present motor type are displayed.
1: Display all. In this mode, all the motor parameters are displayed.
P03 group––Vector control
Function
code
P03.00
Speed-loop integral
P03.01
Low-point frequency
P03.02
P03.03
Speed-loop integral
P03.04
High-point frequency
P03.05
The parameters P03.00–P03.05 are applicable only to vector control mode. Below the switching frequency 1 (P03.02), the
speed-loop PI parameters are: P03.00 and P03.01. Above the switching frequency 2 (P03.05), the speed-loop PI
parameters are: P03.03 and P03.04. PI parameters are obtained according to the linear change of two groups of
parameters. See the following figure:
The speed loop dynamic response characteristics of vector control can be adjusted by setting the proportional coefficient
and integral time of speed regulator. Increasing proportional gain or reducing integral time can accelerate dynamic
Name
Overload protection
20.0%–120.0%
Name
Power calibration
coefficient of motor 1
Name
Parameter display of
motor 1
Name
Speed-loop
0–200.0
proportional gain 1
0.000–10.000s
time 1
0.00Hz–P03.05
for switching
Speed-loop
0.0–200.0
proportional gain 2
0.000–10.000s
time 2
P03.02–P00.03 (Max. frequency)
for switching
PI parameter
P03.00，P03.01
Description
Description
0.01–3.00
Description
0: Display based on motor type
1: Display all
Description
P03.03，P03.04
Output frequency f
P03.02 P03.05
-72-
Goodrive3000 inverter
Setting range Default
20.0–120.0 100.0%
Setting range Default
0.00–3.00 1.00
Setting range Default
0–1 0
Setting range Default
0–200.0 20.0
0.000–10.000 1.000s
0.00–P03.05 5.00Hz
0.0–200.0 20.0
0.000–10.000 1.000s
P03.02–P00.03 10.00Hz
