Goodrive3000 series medium voltage VFD
Note: This part is applicable only to the inverters of the two-quadrant and four-quadrant VFD models.

6.1 Function description

P00 group––Basic functions
Function
code
P00.00 Speed control mode
1: SVC mode 1 (for AM)
No need to install encoders. Applicable to scenarios with requirements for low frequency, great torque, and high speed
control accuracy at all power ratings.
2: V/F control
No need to install encoders. It can improve the control accuracy with the advantages of stable operation, valid
low-frequency torque boost and current vibration suppression and the functions of slip compensation and voltage
adjustment. For detailed settings, see P04 group.
3: Closed-loop vector control mode (for AM, SM)
Need to install encoders. Applicable to scenarios with requirements for low frequency, great torque, and high speed
control accuracy.
Function
code
Channel of running
P00.01
The function code is used to select the channel of running VFD control commands.
The VFD control commands include the start, stop, forward run, reverse run, jogging, and fault reset commands.
0: Keypad ("LOCAL/REMOT" indicator off)
The running commands are controlled through keypad keys, such as the RUN and STOP/RST keys. In running state, you
can press both RUN and STOP/RST to enable the VFD to coast to stop.
1: Terminal ("LOCAL/REMOT" indicator blinking)
The running commands are controlled through multifunction input terminals.
2: Communication ("LOCAL/REMOT" indicator on)
The running commands are controlled by the upper computer in communication mode.
Function
code
P00.02

6 Goodrive3000 inverter

Name
0: SVC mode 0 (for SM)
1: SVC mode 1 (for AM)
2: V/F control
3: Closed-loop vector control mode
Note:
AM-asynchronous motor
SM-synchronous motor
Name
0: Keypad (the indicator is off)
1: Terminal (the indicator blinks)
commands 2: Communication (the indicator is
on)
Name
Communication 0: MODBUS
mode of running 1: PROFIBUS/CANopen
Description
Description
Description
-59-
Goodrive3000 inverter
Setting range Default
0–3 2
Setting range Default
0–2 0
Setting range Default
0–3 0
