INVT Goodrive3000 Series Operation Manual page 102

Goodrive3000 series medium voltage VFD
Function
code
P07.06
The function code P07.06 determines parameter display at VFD running state. The value is a 16-bit binary number. If a bit
is 1, the parameter corresponding to this bit can be viewed through >>/SHIFT during running. If this bit is 0, the parameter
corresponding to this bit is not displayed. When setting P07.05 and P07.06, convert the binary number to a hex number
before the input to the function code.
Note: The options AI3 and HDI are available only when corresponding expansion cards are configured.
BIT15
PLC and
actual step of
multi-step
P07.05
speed
BIT7
Output torque
BIT15
Reserved
BIT7
P07.06
Reserved
Name
BIT2: Bus voltage (V on)
displayed in the
BIT3: Output voltage (V on)
running state
BIT4: Output current (A on)
BIT5: Running speed (rpm on)
Bit 6: Output power (% on)
Bit 7: Output torque (% on)
Bit 8: PID reference value (%
blinking)
Bit 9: PID feedback value (% on)
BIT10: Input terminal status
BIT11: Output terminal status
Bit 12: Set torque (% on)
Bit 13: Pulse count value
BIT14: Reserved
Bit 15: PLC and current step number
of multi-step speed
Bit 0: AI1 (V on)
Bit 1: AI1 (V on)
Bit 2: AI3 (V on)
BIT3: HDI frequency
BIT14: Motor overload percentage (%
Selection 2 of
on)
parameters to be
BIT15: VFD overload percentage (%
displayed in the
on)
running state
Bit 6: Ramp frequency reference (Hz
on)
BIT7: Reserved
BIT8: Reserved
Bit 9–15: Reserved
BIT14 BIT13
Length Pulse
value count value
BIT6 BIT5
Output Rotational
power speed
BIT16 BIT13
Reserved Reserved
BIT6 BIT5
Ramp VFD
frequency overload
reference percentage
Description
BIT12 BIT11
Output
Torque set
terminal
value
status
BIT4 BIT3
Output Output
current voltage
BIT12 BIT11
Reserved Reserved Reserved Reserved Reserved
BIT4 BIT3
Motor
HDI
overload AI3 value AI2 value AI1 value
frequency
percentage
-96-
Goodrive3000 inverter
Setting range Default
0x0000–0xFFFF 0x0000
BIT10 BIT9 BIT8
Input PID
terminal feedback reference
status value value
BIT2 BIT1 BIT0
Bus Set Running
voltage frequency frequency
BIT10 BIT9 BIT8
BIT2 BIT1 BIT0
PID
