INVT Goodrive3000 Series Operation Manual page 232

Goodrive3000 series medium voltage VFD
Function
code
DP communication
P12.25
timeout time
Related function codes for inverter unit
Function
code
P15.00 Module type
PROFIBUS/CANopen
P15.01
module address
P15.02 Received PZD2
P15.03 Received PZD3
P15.04 Received PZD4
P15.05 Received PZD5
P15.06 Received PZD6
P15.07 Received PZD7
P15.08 Received PZD8
P15.09 Received PZD9
P15.10 Received PZD10
P15.11 Received PZD11
P15.12 Received PZD12
P15.13 Sent PZD2
P15.14 Sent PZD3
P15.15 Sent PZD4
P15.16 Sent PZD5
P15.17 Sent PZD6
P15.18 Sent PZD7
P15.19 Sent PZD8
P15.20 Sent PZD9
P15.21 Sent PZD10
P15.22 Sent PZD11
Name
0.0 (invalid), 0.1–60.0s
Name
0: PROFIBUS
0–127
0: Disable
1: Set frequency (0–Fmax (Unit: 0.01Hz))
2: PID
corresponds to 100.0%)
3: PID
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which 1000
corresponds to 100.0% of the motor rated current)
5: Setting of the upper limit of forward running
frequency (0–Fmax, unit: 0.01 Hz)
6: Setting of the upper limit of reverse running
frequency (0–Fmax, unit: 0.01 Hz)
7: Upper limit of the electromotive torque (0–3000,
in which 1000 corresponds to 100.0% of the motor
rated current)
8: Upper limit of braking torque (0–2000, in which
1000 corresponds to 100% of the motor rated
current)
9: Virtual input terminal command. Range: 0x000–
0x1FF
10: Virtual output terminal command. Range: 0x00–
0x0F
11: Voltage setting (special for V/F separation)
(0–1000, in which 1000 corresponds to 100% of the
motor rated voltage)
12: AO output setting 1 (-1000–+1000, in which
1000 corresponds to 100.0%)
13: AO output setting 2 (-1000–+1000, in which
1000 corresponds to 100.0%)
0: Invalid
1: Running frequency (*100, Hz)
2: Set frequency (*100, Hz)
3: Bus voltage (*10, V)
4: Output voltage (*1, V)
5: Output current (x10, A)
6: Actual output torque (x10, %)
7: Actual output power (x10, %)
8: Rotation speed of running (x1, RPM)
9: Linear speed of running (x1, m/s)
Description
Description
reference (0–1000, in
feedback (0–1000, in
-226-
PROFIBUS communication
Setting
range
0.0–60.0s
Setting
range
0–1
0–127
0–20
0–20
which 1000
0–20
0–20
which 1000
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
0–20
Default
0.0s
Default
0
2
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
