The function code is used to enable protection against phase loss.
Function
code
Frequency drop at
P11.01
transient power-off
The function code is used to enable the frequency decrease at sudden power loss.
Function
code
Frequency drop rate
P11.02
at transient power-off
If the bus voltage drops to the sudden frequency decreasing point due to the power loss of the grid, the VFD begins to
decrease the running frequency according to P11.02 to make the motor in power generation state. The feedback power
can maintain the bus voltage to ensure the continuous running of the VFD until the recovery of power.
Voltage class
Frequency decrease point at sudden
power loss (bus voltage)
Note:
1. Adjusting the parameter properly can prevent the stop caused by the VFD protection during shifting the grid.
2. This function can be enabled only when the input phase protection function is disabled.
Function
code
Overvoltage stalling
P11.03
The function code is used to enable the protection against overvoltage stalling.
Function
code
Overvoltage stalling
P11.04
protection voltage
Name
loss enabled
Tens place:
0: Protection against output phrase
loss disabled
1: Protection against output phrase
loss enabled
Name
0: Disable
1: Enable
Name
0.00Hz/s–P00.03 (Max. output
frequency)
Name
0: Disable
protection 1: Enable
DC bus voltage V
Overvoltage stall
threshold
Output
frequency
Name
110–150% (standard bus voltage)
Description
Description
Description
660V 1140V
700V 1350V
Description
Description
-115-
Goodrive3000 inverter
Setting range Default
Setting range Default
0–1 0
Setting range Default
0.00–P00.03 1.00Hz/s
3300V
3900V
Setting range Default
0–1 0
Time t
Time t
Setting range Default
110–150 125%
