Goodrive3000 series medium voltage VFD
Function
code
P15.23 Sent PZD12
Temporary variable 1
P15.24
for PZD sending
DP communication
P15.25
timeout time
CAN communication
P15.26
timeout time
P15.27 communication baud
CAN communication
P15.28
CAN communication
P15.29
Name
10: Ramp reference frequency
11: Fault code
12: AI1 input (*100, V)
13: AI2 input (*100, V)
14: AI3 input (* 100, V)
15: PULSE frequency value (x100, kHz)
16: Terminal input status
17: Terminal output status
18: PID reference (x100, %)
19: PID feedback (x100, %)
20: Motor rated torque
0–65535
0.0 (invalid), 0.1–60.0s
0.0 (invalid), 0.1–60.0s
0: 1000k
1: 800k
2: 500k
CANopen
3: 250k
4: 125k
rate
5: 100k
6: 50k
7: 20k
0–127
address 0 indicates a broadcast address
0: 1000k
1: 500k
2: 250k
baud rate
3: 125k
4: 100k
Description
-227-
PROFIBUS communication
Setting
Default
range
0–20 0
0–65535 0
0.0–60.0 0.0s
0.0–60.0 0.0s
0–7 0
0–127 1
0–4 1
