Goodrive3000 series medium voltage VFD
Function
code
The function code is used to select the output voltage setting channel at V/F curve separation.
Note: 100% corresponds to the motor rated voltage. The options 3, 4, 8, and 9 are available only when
corresponding expansion cards are configured.
Function
code
Voltage set through
P04.28
The function code is the voltage digital setting when "keypad" is selected (P04.27=0) as the voltage setting channel.
Function
code
P04.29 Voltage increase time 0.0–3600.0s
P04.30
Voltage increase time means the time needed for the VFD to accelerate from 0V to the motor rated frequency.
Voltage decrease time means the time needed for the VFD to decelerate from the rated output frequency to 0V.
Function
code
P04.31 Max. output voltage
P04.32 Min. output voltage 0.0%–P04.31 (motor rated voltage)
The function codes are used to set the upper and lower limits of output voltage.
Function
code
VF automatic torque
P04.33
Reactive closed-loop
P04.34 proportional gain in
Reactive closed-loop
P04.35 integral gain in VF
Name
7: MODBUS communication
8: PROFIBUS/CANopen
communication
9: Ethernet communication
10: Reserved
Name
0.0%–100.0% (of the motor rated
keypad voltage)
Name
Voltage decrease
0.0–3600.0s
time
Name
P04.32 –100.0% (of the motor rated
voltage)
Vmax
V set
Vmin
Name
boost cut-in 0.00–400.00Hz
frequency
0–5000 (Canceled when P04.34=0)
VF control
0–5000
control
Description
Description
Description
Description
t1=P04.29
t2=P04.30
t1 t2
Time t
Description
-80-
Goodrive3000 inverter
Setting range Default
Setting range Default
0.0–100.0 100.0%
Setting range Default
0.0–3600.0 5.0s
0.0–3600.0 5.0s
Setting range Default
0.0–100.0 100.0%
0.0–100.0 0.0%
Setting range Default
0.00–400.00 2.00Hz
0–5000 50
0–5000 30
