INVT Goodrive3000 Series Operation Manual page 112

Goodrive3000 series medium voltage VFD
Function
code
The function code is used to set the control function of the keypad.
Function
code
P08.43
potentiometer integral time
UP/DOWN terminal control
P08.44
The function codes set the control functions of UP/DOWN terminals.
Function
code
P08.45
Frequency change rate of
P08.46
The function codes are used to set the integral ratio of UP/DOWN terminals.
Name
2: Valid during running, cleared after a
stop command is received
Thousands place: Integral function of the
∧/∨ key and digital potentiometer
0: Enable the integral function
1: Disable the integral function
Name
Keypad digital
0.01–10.00s
0x000–0x221
Ones place: Frequency setting
enabling
0: The setting made through
UP/DOWN is valid.
1: The setting made through
UP/DOWN is invalid.
Tens place: Frequency setting
selection
0: Valid only when P00.06=0 or
P00.07=0
1: Valid for all frequency setting
setting
methods
2: Invalid for multi-step speed running
when multi-step speed running has
the priority
Hundreds place: Action selection for
stop
0: Setting is valid.
1: Valid during running, cleared after
stop
2: Valid during running, cleared after a
stop command is received
Name
Frequency increment
change rate of the UP
terminal
the DOWN terminal
Description
Description
Description
0.01–50.00s
0.01–50.00 s
-106-
Goodrive3000 inverter
Setting range Default
Setting range Default
0.01–10.00 0.1
0x000–0x221 0x000
Setting range Default
0.01–50.00 0.50s
0.01–50.00 0.50s
