INVT Goodrive3000 Series Operation Manual page 163

Goodrive3000 series medium voltage VFD
Function
code
P05.10 Input terminal polarity
P05.11 Digital input filter time
P05.12 Virtual terminal setting
P05.13 Terminal control mode
P05.14 S1 switch-on delay
Name
27: Reserved
28: Reserved
29: Disable torque control
30: Disable ACC/DEC
31: Reserved
32: Reserved
33: Clear the frequency
increase/decrease setting
temporarily
34: DC braking for stop
35: Switch from motor 1 to motor
2
36: Switch the running command
channel to keypad
37: Switch the running command
channel to terminal
38: Switch the running command
channel to communication
39: Pre-exciting command
40: Clear electricity consumption
41: Keep electricity consumption
42: External fault input 2
43: Enable switching to power
frequency run
44: Switch to the master
45: Switch to the slave
46: Switch-on signal feedback of
rectifier
47–63: Reserved
0x000–0x1FF
0.000–1.000s
0: Virtual input terminals are
invalid
1: MODBUS communication
virtual terminals are valid
2: PROFIBUS/CANopen
communication virtual terminals
are valid
3: Ethernet virtual terminals are
valid
4: Reserved
0: Two-wire control mode 1
1: Two-wire control mode 2
2: Three-wire control mode 1
3: Three-wire control mode 2
0.000–50.000s
Description
0.000–1.000
-157-
Goodrive3000 inverter
Setting
Default Modify
range
0x000–
0x000
0x1FF
0.010s
0–4 0
0–3 0
0.000–
0.000s
50.000
○
○
◎
◎
○
