Goodrive3000 Four-Quadrant Vfd Main Ratings; Product Standards - INVT Goodrive3000 Series Operation Manual

Goodrive3000 series medium voltage VFD
VFD model
U =3300V
N
GD3000-01-1500G-33
GD3000-01-1600G-33
GD3000-01-2500G-33

2.4.2 Goodrive3000 four-quadrant VFD main ratings

VFD model
U =660V
N
GD3000-11-110G-06
GD3000-11-160G-06
GD3000-11-200G-06
GD3000-11-250G-06
GD3000-11-315G-06
GD3000-11-400G-06
GD3000-11-500G-06
GD3000-11-630G-06
GD3000-11-800G-06
VFD model
U =1140V
N
GD3000-11-055G-12
GD3000-11-075G-12
GD3000-11-090G-12
GD3000-11-110G-12
GD3000-11-132G-12
GD3000-11-160G-12
GD3000-11-200G-12
GD3000-11-250G-12
GD3000-11-315G-12
GD3000-11-400G-12
GD3000-11-500G-12
GD3000-11-630G-12
GD3000-11-800G-12
GD3000-11-1000G-12
VFD model
U =3300V
N
GD3000-11-1500G-33
GD3000-11-2500G-33

2.5 Product standards

The Goodrive3000 series medium voltage speed regulation system is designed and manufactured with reference to the
latest version of national standards (GB or GB/T), International Electrotechnical Commission (IEC) standards, and
International System of Units (SI) as the minimum design specifications, and some of its relevant technical parameters
can meet the requirements of GB or GB/T and IEC standards.
Rated power (kW)
1500
1600
2500
Table 2-6 Goodrive3000 four-quadrant VFD main ratings
Rated power (kW)
110
160
200
250
315
400
500
630
800
Rated power (kW)
55
75
90
110
132
160
200
250
315
400
500
630
800
1000
Rated power (kW)
1500
2500
Rated input current (A) Rated output current (A)
300
330
540
Rated input current (A) Rated output current (A)
101
147
184
230
290
368
460
580
736
Rated input current (A) Rated output current (A)
30
40
49
58
70
85
106
133
168
213
265
335
425
530
Rated input current (A) Rated output current (A)
265
442
-10-
Product overview
320
360
565
120
175
220
270
350
430
540
700
860
36
50
60
73
85
104
128
160
195
250
310
395
500
620
320
565
