INVT Goodrive3000 Series Operation Manual page 56

Goodrive3000 series medium voltage VFD
Function
code
P05.20–
P05.27
P05.28 AI1 lower limit
Corresponding setting of
P05.29
AI1 lower limit
P05.30 AI1 upper limit
Corresponding setting of
P05.31
AI1 upper limit
P05.32 AI1 input filter time
P05.33 AI2 lower limit
Corresponding setting of
P05.34
AI2 lower limit
P05.35 AI2 middle value
Corresponding setting of
P05.36
AI2 middle value
P05.37 AI2 upper limit
Corresponding setting of
P05.38
AI2 upper limit
P05.39 AI2 input filter time
P05.40 AI3 lower limit
Corresponding setting of
P05.41
AI3 lower limit
P05.42 AI3 upper limit
Corresponding setting of
P05.43
AI3 upper limit
P05.44 AI3 input filter time
P06 group––Output terminals
Digital output terminal
P06.00
P06.01 Relay RO1 output
P06.02 Relay RO2 output
P06.03–
P06.04
Name
Reserved
0.00V–P05.30
-100.0%–100.0%
P05.28–10.00V
-100.0%–100.0%
0.000s–10.000s
-10.00V–P05.35
-100.0%–100.0%
P05.33–P05.37
-100.0%–100.0%
P05.35–10.00V
-100.0%–100.0%
0.000s–10.000s
0.00V–P05.42
-100.0%–100.0%
P05.40–10.00V
-100.0%–100.0%
0.000s–10.000s
0x0–0xF
0 indicates positive.
BIT0: RO1
polarity
BIT1: RO2
BIT2–BIT7: Reserved
0: No output
1: Ready for running
2: Running
3: Fault output
Reserved
4–31: Reserved
Description
-50-
Goodrive3000 rectifier
Setting
Default Modify
range
0.00–
0.00V
P05.30
-100.0–
0.0%
100.0
P05.28–
10.00V
10.00
-100.0–
100.0%
100.0
0.000–
0.100s
10.000
-10.00–
-10.00V
P05.35
-100.0–
-100.0%
100.0
P05.33–
0.00V
P05.37
-100.0–
0.0%
100.0
P05.35–
10.00V
10.00
-100.0–
100.0%
100.0
0.000–
0.100s
10.000
0.00–
0.00V
P05.42
-100.0–
0.0%
100.0
P05.40–
10.00V
10.00
-100.0–
100.0%
100.0
0.000–
0.100s
10.000
0x0–0xF 0x0
1
2
0–31
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
