Cooling-fan running
P00.10
The function code is used to set the cooling-fan running mode.
0: Normal running mode: after the rectifier receives the running command or the detection temperature of the rectifier is
higher than 45° C or the current of the rectifier is higher than 50% of the rated current, the cooling fan will run.
1: Permanent running after power-on (applicable to high temperature and humidity situations)
Function
code
P00.14
Function parameter
P00.15
0: No operation
1: Restore default values. The PWM rectifier restores default values for parameters.
2: Clear fault records. The PWM rectifier clears recent fault records.
3: Clear accumulative power consumption. The PWM rectifier clears accumulative electricity consumption.
Note: 1. After the selected operation is performed, the function code is automatically restored to 0.
2. Restoring the default values may delete the user password. Exercise caution when using this function.
Function
code
Function parameter
P00.16
Note: When P00.16=1, all other function codes except P00.16 are read only and no other operations can be
performed.
P01 group––Power-on control and protection
Function
code
Detecting main contactor
P01.01
Pre-charging buffer circuit is in the rectification part and when the charging voltage exceeds the set value, the contactor is
switched on and the charging resistor is switched off.
When P01.01=1, if there is switching-on command but no feedback signal, or there is feedback signal but no switching-on
command, it will report main contactor fault (TbE).
When P01.01=0, then there is no detection on main contactor fault (TbE).
Note: 1. The switching-on signal is only controlled by the control board.
2. For other power-on logics, a non-standard solution can be offered.
Name
0: Normal mode
mode 1: Permanent running after power-on
Name
Carrier frequency 2.0–8.0kHz
0: No operation
1: Restore default values
2: Clear fault records
restore
3: Clear accumulative electricity
consumption
Name
0: Invalid
property 1: Read only
Name
0: Not detect
actuation feedback 1: Detect
Description
Description
Description
Description
-23-
Goodrive3000 rectifier
Setting range Default
0–1 0
Setting range Default
Model
2.0–8.0
depended
0–3 0
Setting range Default
0–1 0
Setting range Default
0–1 1
