P19 group––External temperature detection
Function code
P19.00
P19.01
P19.02
P19.03
P19.04
P19.05
P19.06
P19.07
P19.08
P19.09
P19.10
P19.11
Name
Max. lower bus voltage
recorded by the system
Sum of three phase
currents
Speed display selection
in vector control
Name
Motor temperature
detection
Motor temperature
pre-alarm point
Motor over-temperature
fault point
Motor overtemperature
action
Starting temperature of
motor temperature
compensation
Motor temperature
compensation
coefficient
Output voltage
compensation enabling
Deadzone
compensation regulation
coefficient
Overvoltage stalling
current inner loop Kp
Overvoltage stalling
current inner loop Ki
PT100 temperature
display channel
Temperature of the
channel selected by
P19.10
Description
0.0–3275.0V
0–65535
0: Identification speed
1: Ramp reference
Description
0: Invalid
1: PT100
2: PTC
3–4: Reserved
0℃–200℃
0℃–200℃
0: Report a fault and coast to
stop
1: Keep running
reporting a fault
2: Stop according to the stop
mode without generating a
fault
0–60.0℃
0.0–200.0%
0: Disabled
1: Enable
0.0–50.0
0–1000
0–1000
0–6
0.0–120.0° C
-131-
Setting range
0.0–3275.0
0–65535
0–1
Setting range
0–4
0° C–200° C
(0° C: pre-alarm
invalid)
0° C–200° C
(0° C: pre-alarm
invalid)
without
0–2
0–60.0
0.0–200.0
0–1
0.0–50.0
0–1000
0–1000
0–6
0.0–120.0
Goodrive3000 inverter
Default
0.0
0
0
Default
0
125° C
150° C
0
40.0° C
100.0%
1
1.0
50
250
0.0
0.0° C
