8.6.2 Related function codes for Goodrive3000 inverter

Functio
n code
P14.00 communication
address
Communication
P14.01
baud rate
P14.02 Data bit check
Communication
P14.03
response delay
Communication
P14.04
timeout time
Transmission error
P14.05
processing
Communication
P14.06
processing action
Name
0x00–0x11
Ones place:
0: Respond to write operations
1: Not respond to write operations
Tens place:
0: Reserved
1: Reserved
Name
Local
1–247; 0 indicates a broadcast address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
6: 57600BPS
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
0–200ms
0.0 (invalid); 0.1–60.0s
0: Report an alarm and coast to stop
1: Keep running without reporting an alarm
2: Stop in enabled stop mode without reporting an
alarm (applicable only to communication mode)
3: Stop in enabled stop mode without reporting an
alarm (applicable to any mode)
Ones place: Action upon the write operation
0: Respond to write operations
1: Not respond to write operations
Tens place: Communication encryption
0: Disabled
1: Enabled
Description
Description
-209-
Moudbus protocol
Setting
Default
range
0x00–0x11 0x00
Setting
Default
range
1–247 1
0–7 4
0–5 1
0–200 5
0.0–60.0 0.0s
0–3 0
0x00–0x11 0x00
