The setting 100.0% corresponds to the max. output frequency (P00.03).
When simple PLC operation is selected, it is required to set P10.02–P10.33 to determine the running frequency and
direction of each step.
Note: The symbol of multi-step speed determines the running direction of simple PLC, and the negative value
means reverse running.
Multi-step speed can be set continuously in the range of -fmax–fmax.
The VFD can set 16-step speeds, which are selectable by multi-step speed terminals 1–4, corresponding to multi-step
speed 0 to multi-step speed 15.
When S1, S2, S3, and S4 are OFF, the frequency input mode is set by P00.06 or P00.07. When S1, S2, S3, and S4 are
not all OFF, the VFD runs at multi-step speed and the multi-step speed has the priority over the keypad, analog values,
high-speed pulse, PLC and communication frequency input. Select at most 16-step speed via the the combined codes of
S1, S2, S3 and S4.
The start-up and stop of multi-step speed is determined by the function code P00.01. The relationship between the
terminals of S1, S2, S3 and S4 and the multi-step speed is shown as follows:
S1 OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
S2 OFF OFF ON
S3 OFF OFF OFF OFF ON
S4 OFF OFF OFF OFF OFF OFF OFF OFF ON
Step 0 1
