Goodrive3000 series medium voltage VFD
response of speed loop; however, if the proportional gain is too large or integral time is too small, system oscillation and
overshoot may occur; if proportional gain is too small, stable oscillation or speed offset may occur.
PI parameters have a close relationship with the inertia of the system. Adjust PI parameters depending on different loads
to meet various demands.
Function
code
Speed-loop output
P03.06
The function code is used to set the filter time of the speed loop.
Function
code
P03.07 compensation coefficient of
Braking slip compensation
P03.08
coefficient of vector control
Slip compensation coefficient is used to adjust the slip frequency of the vector control and improve the speed control
accuracy of the system. Adjusting the parameter properly can control the speed steady-state error.
Function
code
P03.09
Current-loop integral
P03.10
Note:
1. The two function codes impact the dynamic response speed and control accuracy of the system. Generally,
you do not need to modify the two function codes.
2. Applicable to SVC mode 1 (P00.00=1) only.
Function
code
P03.11
The function code is used to enable the torque control mode and set the torque setting method.
Note:
1. For setting methods 2–15, 100% corresponds to triple the motor rated current.
Name
0–8 (corresponding to 0–2
filter
Name
Electromotive slip
vector control
Name
Current-loop
proportional 0–65535
coefficient P
0–65535
coefficient I
Name
0: Torque control invalid
1: Keypad (P03.12)
2: AI1
3: AI2
4: AI3
Torque setting
5: Pulse frequency HDI
method
6: Multi-step torque
7: MODBUS communication
8: PROFIBUS/CANopen communication
9: Ethernet communication
10: Reserved
Description
8
/10ms)
Description
50%–200%
50%–200%
Description
Description
-73-
Goodrive3000 inverter
Setting range Default
0–8 0
Setting range Default
50–200 100%
50–200 100%
Setting range Default
0–65535 1000
0–65535 1000
Setting range Default
0–10 0
