INVT Goodrive3000 Series Operation Manual page 194

Goodrive3000 series medium voltage VFD
Function
code
P23 group––Storage function of communication SD card
P23.00 Memory enabling
P23.01
P23.02
P23.03
P23.04
Recorded value of half bus
P23.05
voltage deviation
P23.06
Data logging trigger
P23.07
Sampling channel 1
P23.08
Sampling channel 2
P23.09
P23.10 Sampling channel 3
P23.11 Sampling channel 4
P23.12 Sampling channel 5
P23.13 Sampling channel 6
P23.14 Sampling channel 7
P23.15 Sampling channel 8
P23.16 Sampling channel 9
Sampling channel 10
P23.17
Name
0:
communication)
1: Enable (SD card storage)
Year setting 0000–9999
Date setting 01.01–12.31
Time setting 00.00–23.59
Seconds setting 00–59
0.0–1000.0
Size of file 2 0–1024
0: Start upon power-on and stop
upon power-off
1: Start upon running and stop
conditions upon stop
2: Triggered through terminals
(electrical level)
0: No function
1: Running frequency
2: Set frequency
3: Ramp reference frequency
4: Output current
5: Output torque
6: Output voltage
7: Bus voltage
8: Running speed
9: AI1
10: AI2
11: AI3
12: AO1
13: AO2
14: HDI input frequency
15: HDO output frequency
16: Terminal input status
17: Relay output status
18: Reserved
19:control_step
20:run_step
21:comd_control
22:status_run_stop
23:status_control
24:comd_run_stop
25:ft_flag
26:ft_sch
27:pre_magtok
28:SynRotorZeroFlag1
29–41: Reserved
42: VFD CW (Uint16)
43: Torque setting (int16)
44: Torque current feedback
(int16)
Description
Disable (Ethernet
-188-
Goodrive3000 inverter
Setting
Default Modify
range
0–1 1
0000–9999 2019
01.01–12.31 01.01
00.00–23.59 0.00
00–59 00
0.0–1000.0 200.0
0–1024 50
0–2 0
0–79 1
0–79 3
0–79 4
0–79 6
0–79 7
0–79 29
0–79 22
0–79 52
0–79 53
0–79 62
