Goodrive3000 series medium voltage VFD
Function
code
P08.14
When the set frequency is within the range of jump frequency, the VFD runs at the boundary of jump frequency.
The VFD can avoid mechanical resonance points by setting jump frequencies. The VFD supports the setting of three jump
frequencies. If the jump frequency points are set to 0, this function is invalid.
Function
code
P08.27
The function code is used to preset the running tine of the VFD. When the accumulative running time achieves the set
time, the multi-function digital output terminal will output the signal of "running time reached".
Function
code
P08.28
P08.29
Auto fault reset count: When the VFD uses automatic fault reset, it is used to set the number of automatic fault reset times.
When the number of continuous reset times exceeds the value, the VFD reports a fault and stops.
Auto fault reset interval: Time interval from when a fault occurred to when automatic fault reset takes effect.
Function
code
Frequency decrease
P08.30
ratio in drop control
The output frequency of the VFD changes as the load changes. The function code is mainly used to balance the power
when several motors drive a same load.
Function
code
Switching between
P08.31
motor 1 and motor 2
The VFDs support the switchover between two motors and the function code is used to switch the channels.
Function
code
FDT1 electrical level
P08.32
Name
Jump frequency
0.00–P00.03 (Max. output frequency)
amplitude 3
Set frequency f
Jumping
frequency3
Jumping
frequency2
Jumping
frequency1
Name
Set running time 0–65535min
Name
Auto fault reset count
Auto fault reset interval
Name
0.00–50.00Hz
Name
0: Terminal
1: MODBUS communication
2: PROFIBUS/CANopen
communication
3: Ethernet communication
4: Reserved
Name
0.00–P00.03 (Max. output frequency)
detection value
Description
1/2*jumping range 3
1/2*jumping range 3
1/2*jumping range 2
1/2*jumping range 2
1/2*jumping range 1
1/2*jumping range 1
Time t
Description
Description
0–10
0.1–3600.0s
Description
Description
Description
-103-
Goodrive3000 inverter
Setting range Default
0.00–P00.03 0.00Hz
Setting range Default
0–65535 0min
Setting range Default
0–10 0
0.1–3600.0 1.0s
Setting range Default
0.00–50.00 0.00Hz
Setting range Default
0–4 0
Setting range Default
0.00–P00.03 50.00Hz
