Goodrive3000 series medium voltage VFD
The description is as follows:
Function
code
P10.34
P10.35
Select corresponding acceleration/deceleration time, and then convert 16-bit binary number into decimal number, finally,
and then set corresponding function codes.
Function
code
P10.36
The function code is used to set the PLC restart mode.
0: Restart from the first step, namely if the VFD stops during running (caused by stop command, fault or power down), it
will run from the first step after restart.
1: Continue running from the step frequency when interruption occurred, namely if the VFD stops during running (caused
by stop command or fault), it will record the running time of current step, and enters this step automatically after restart,
then continue running at the frequency defined by this step in the remaining time.
Function
code
P10.37
The function code is used to set the time unit.
0: second; the running time of each step is counted in seconds
1: minute; the running time of each step is counted in minutes
P11 group––Protection
Function
code
P11.00
Binary
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
Name
0: Restart from step 1
PLC restart mode
1: Resume from the paused step
Name
0: Second
Multi-step time unit
1: Minute
Name
0x00–0x11
Ones place:
Protection against
0: Protection against input phrase
phase loss
loss disabled
1: Protection against input phrase
ACC/DEC
Step ACC/DEC T2 ACC/DEC T3 ACC/DEC T4
time 1
0 00
1 00
2 00
3 00
4 00
5 00
6 00
7 00
8 00
9 00
10 00
11 00
12 00
13 00
14 00
15 00
Description
Description
Description
-114-
Goodrive3000 inverter
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
01 10
Setting range
0–1
Setting range
0–1
Setting range
0x00–0x11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
Default
0
Default
0
Default
0x11
