Goodrive3000 series medium voltage VFD
Function
code
Reactive current closed-loop
P04.37
high-frequency integral
Reactive closed-loop voltage
P04.38
limit in PM-VF control
P04.39 IF enabling selection
P04.40 IF control current
P04.41 IF control proportional gain 0–5000
P04.42 IF control integral gain
P04.43 IF switching off frequency 0.00–20.00Hz
P05 group––Input terminals
P05.00
P05.01 Function of S1 terminal
P05.02 Function of S2 terminal
P05.03 Function of S3 terminal
P05.04 Function of S4 terminal
P05.05 Function of S5 terminal
P05.06 Function of S6 terminal
P05.07 Function of S7 terminal
P05.08 Function of S8 terminal
P05.09
Name
0–5000
0–16000V
0: Invalid
1: Valid
0.0–200.0%
0–5000
0: HDI is high-speed pulse input
HDI input type
1: HDI is digital input
0: No function
1: Forward running
2: Reverse running
3: Three-wire running control
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Fault reset
8: Pause running
9: External fault input
10: Increase frequency setting
(UP)
11: Decrease frequency setting
(DOWN)
12: Clear the frequency
increase/decrease setting
13: Switch between A setting and
B setting
14: Switch between combination
setting and A setting
15: Switch between combination
setting and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
Function of HDI
20: Pause multi-step speed
running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
23: Simple PLC stop reset
24: Pause simple PLC
25: Pause PID control
26: Reserved
Description
-156-
Goodrive3000 inverter
Setting
Default Modify
range
0–5000 30
0–16000 8000V
0–1 0
0.0–200.0 50.0%
0–5000 350
0–5000 10
0.00–20.00 10.00Hz
0–1 0
0–63 1
0–63 4
0–63 7
0–63 0
0–63 0
0–63 0
0–63 0
0–63 0
0–63 0
○
○
◎
○
○
○
○
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
