Goodrive3000 series medium voltage VFD
Function
code
P15.13
P15.14
P15.15
P15.16
P15.17
P15.18
P15.19
P15.20
P15.21
P15.22
P15.23
The following table describes the second PZD words in the PROFIBUS-DP communication with the master. For the VFD,
the words are sent.
Functio
n code
0
1 Running frequency
2 Set frequency
3
4 Output voltage
5 Output current
6 Actual output torque
7 Actual output power
8 Rotational speed
9 Running linear speed
10 Ramp reference frequency
11
12
13
14
15 PULSE frequency
16 Terminal input status
17 Terminal output status
18 PID reference
19 PID feedback
20 Motor rated torque
Name
Sent PZD2 0: Disable
1: Running frequency
Sent PZD3
2: Set frequency
Sent PZD4
3: Bus voltage
Sent PZD5
4: Output voltage
Sent PZD6
5: Output Current
Sent PZD7
6: Actual output torque
Sent PZD8
7: Actual output power
Sent PZD9
8: Rotational speed
Sent PZD10
9: Running linear speed
Sent PZD11
10: Ramp reference frequency
11: Fault code
12: AI1 input
13: AI2 input
14: AI3 input
15: PULSE frequency
Sent PZD12
16: Terminal input status
17: Terminal output status
18: PID reference
19: PID feedback
20: Motor rated torque
Name
Invalid
(*100, Hz)
(*100, Hz)
Bus voltage (*10, V)
(*1, V)
(*10, A)
(*10, %)
(*10, %)
(*1, RPM)
(*1, m/s)
Fault code
AI1 input (*100, V)
AI2 input (*100, V)
AI3 input (*100, V)
(*100, kHz)
(*100, %)
(*100, %)
Description
Description
-125-
Goodrive3000 inverter
Setting range Default
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
