INVT Goodrive3000 Series Operation Manual page 134

Goodrive3000 series medium voltage VFD
Function
code
P17.05 Motor rotation speed
P17.06 Torque current
P17.07 Exciting current
P17.08 Motor power
P17.09 Output torque
Estimated motor
P17.10
P17.11 DC bus voltage
Digital input terminal
P17.12
Digital output terminal
P17.13
Digital adjustment
P17.14
Torque reference
P17.15
P17.19 AI1 input voltage
P17.20 AI2 input voltage
P17.21 AI3 input voltage
P17.22 HDI input frequency
P17.23 PID reference value
Name
current of the VFD. 0.0–3000.0A
Displays the current motor speed.
0–65535RPM
Displays the present torque current of the
VFD. -3000.0–3000.0A
Displays the present exciting current of
the VFD. -3000.0–3000.0A
Displays the present motor power. 100%
corresponds to the rated motor power.
The positive value is the motoring state
while the negative value is the generating
state.
-300.0 –300.0% (of the motor rated
power)
Displays the present output torque of the
VFD. 100% corresponds to the motor
rated torque. The positive value is the
motoring state while the negative value is
the generating state.
-250.0–250.0%
Displays
frequency under the open-loop vector
frequency condition.
0.00Hz–P00.03
Displays the present DC bus voltage of
the VFD. 0.0V–6000.0V
Displays the present digital input terminal
state of the VFD.
status
0x0000–0x00FF
Displays the present digital output terminal
state of the VFD.
status
0x0000–0x000F
Displays the adjustment on the VFD
value through the keypad. 0.00Hz–P00.03
Relative to the percentage of the rated
torque of the present motor, displaying the
torque reference.
value
-300.0%–300.0% (of the motor rated
current)
Displays the AI1 input signal.
0.00–10.00V
Displays the AI2 input signal. -10.00–
10.00V
Displays the AI3 input signal. 0.00–10.00V
Display HDI input frequency.
0.00–50.00kHz
Displays the PID reference value.
-100.0–100.0%
Description
the estimated motor
-128-
Goodrive3000 inverter
Setting range Default
0–65535
-3000.0–3000.0
-3000.0–3000.0
-300.0–300.0
-250.0–250.0
rotor
0.00–P00.03 0.00Hz
0.0–6000.0
0x0000–
0x0000
0x00FF
0x0000–
0x0000
0x000F
0.00–P00.03 0.00Hz
-300.0–300.0
0.00–10.00
-10.00–10.00
0.00–10.00
0.00–50.00 0.00kHz
-100.0–100.0
0 rpm
0.0A
0.0A
0.0%
0.0%
0V
0.0%
0.00V
0.00V
0.00V
0.0%
