Goodrive3000 series medium voltage VFD
P20 group––Encoders
Function
code
P20.00
The function code is used to select an encoder type.
Note: An expansion card is required.
Function
code
P20.01 Encoder pulse count 0–60000
The function code is used to set the encoder pulse number per rotation.
Function
code
P20.02
Note: Please set the encoder pulse number correctly under the closed loop vector control mode (P20.01);
otherwise, the motor will not run properly. If it still cannot run properly after parameter setting of the encoder,
change the encoder direction (P20.02).
Function
code
P20.03
encoder offline fault
P20.04
encoder reversal fault
P20.05
encoder detection
P20.03 defines encoder offline detection time. When the offline time exceeds the set time, the VFD will alarm encoder
offline fault (ENCIO).
P20.04 defines encoder reverse detection time. When the reverse detection time exceeds the set time, the VFD will alarm
encoder reverse fault (ENCID).
Note: Adjusting above parameters will influence the flexibility of encoder fault protection and sometimes
abnormal actions may occur, so adjust carefully.
Function
code
Speed ratio between
P20.06
motor and encoder
The function code is used to set the speed ratio between motor and encoder. Set the value according to the actual
conditions.
Name
0: Incremental encoder
Encoder type 1: Reserved
selection 2: Resolver-type encoder
3: Reserved
Name
Name
0x00–0x11
Ones place: AB direction
0: Forward
Encoder direction 1: Reverse
Tens place: Z pulse direction
0: Forward
1: Reverse
Name
Detection time of
0.0–100.0s
Detection time of
0.0–100.0s
Filter times of Ones place: Low-speed filter time
Tens place: High-speed filter time
Name
0.000–65.535
Description
Description
Description
Description
Description
-132-
Goodrive3000 inverter
Setting range Default
0–3 0
Setting range Default
0–60000 1024
Setting range Default
0x00–0x11 0x00
Setting range Default
0.0–100.0 0.5s
0.0–100.0 0.8s
00xx–0x99 0x23
Setting range Default
0.000–65.535 1.000
