Goodrive3000 series medium voltage VFD
Function
code
The function code determines the target given channel during the PID process. When the frequency command selection
(P00.06, P00.07) is 7 or the voltage setting channel selection (P04.27) is 6, the VFD is process PID controlled.
The set target of process PID is a relative value, for which 100% equals 100% of the feedback signal of the controlled
system.
The system always performs calculation by using a relative value (0–100.0%).
Note:
1. Multi-step speed reference can be realized by setting parameters of P10 group.
2. The options 3, 4, 7, and 8 are available only when corresponding expansion cards are configured.
Function
code
P09.01
When P09.00=0, the parameter is set on the keypad.
Function
code
P09.02 PID feedback source
The function code is used to select PID feedback channel.
Note:
1. The reference channel and feedback channel cannot be duplicate. Otherwise, effective PID control cannot
be achieved.
2. The options 2, 3, 5, and 6 are available only when corresponding expansion cards are configured.
Function
code
P09.03
The function code is used to select PID output characteristics.
Name
2: AI2
3: AI3
4: High-speed pulse HDI
5: Multi-step running
6: MODBUS communication
7: PROFIBUS/CANopen
communication
8: Ethernet communication
9: Reserved
Name
PID digital setting -100.0%–100.0%
Name
0: AI1
1: AI2
2: AI3
3: High-speed pulse HDI
4: MODBUS communication
5: PROFIBUS/CANopen
communication
6: Ethernet communication
7: Reserved
Name
PID output
0: PID output is positive.
characteristics
1: PID output is negative.
selection
Description
Description
Description
Description
-108-
Goodrive3000 inverter
Setting range Default
Setting range Default
-100.0–100.0 0.0%
Setting range Default
0–7 0
Setting range Default
0–1 0
