Goodrive3000 series medium voltage VFD
Function
code
P08.20 IGBT temperature
P10 group––Fault information
Function
code
P10.00
P10.01
P10.02 2nd-last fault type
P10.03
P10.04
P10.05
Name
value.
1.00–10.00
Displays the IGBT temperature of the
rectifier.
-20.0–120.0℃
Name
Present fault type Common fault type:
00: No fault
Last fault type
01: Input overcurrent (OC)
02: Grid undervoltage (Lv1)
3rd-last fault type
03: Grid overvoltage (Ov1)
4th-last fault type
04: Grid phase loss (SPI)
05: Phase lock failure (PLLF)
06: DC undervoltage (Lv)
07: DC overvoltage (ov)
08: Current detection fault (ItE)
09: PROFIBUS communication fault
(E-DP)
10: RS485 communication fault (CE)
11: CANopen communication fault
(E-CAN)
12: Ethernet communication fault
(E-NET)
13: Half bus overvoltage (HOV)
14: Upper and lower bus voltage
imbalance (VH2)
15: Rectifier overload (OL)
16: EEPROM operation error (EEP)
5th-last fault type
17: Main contactor actuation failure
(TbE)
18: 3PH current imbalance detection
(PIF)
19: DSP-FPGA communication fault
(dF_CE)
20: External fault (EF)
21: Rectifier disabled (dIS)
22: Keypad fault (PCE)
23: Parameter upload fault (UPE)
24: Parameter download fault (DnE)
25: Running time reached (END)
26: Power-on buffer half-voltage
timeout (PC_t1)
27: Slave communication fault
(E_ASC)
28: Slave fault (E-SLE)
Description
Description
-36-
Goodrive3000 rectifier
Setting range Default
-20.0–120.0 0.0° C
Setting range Default
0
0
0
0
0
0–31
or
m.01–m.16
(m=1, 2, 3...6)
0
