INVT Goodrive3000 Series Operation Manual page 33

Goodrive3000 series medium voltage VFD
Function
code
Overmodulation entry
P03.25
P03.26 proportional coefficient
P03.27
P03.28
P03.29
P03.30
P03.31
P03.32
P03.33
adjustment coefficient
P03.34–
P03.35
Rectifier phase shifting
P03.36
Upper limit of voltage
P03.37
P03.38
Name
entry point
0: Invalid
1: Valid
0.0–100.0% (modulation degree)
point
Overmodulation
0.001–60.000
P
Overmodulation
0.01–30.000
integral coefficient I
Phase-lock loop
0–10
integral
Reserved
Enabling high grid 0: Disable
voltage 1: Enable
High grid voltage
0–10
adjustment Kp
High grid voltage
0–100
adjustment Ki
PLL impedance
0.00–5.00
Reserved
The function code is used to
compensate the phase angle of
phase lock. A positive value
indicates that the phase-locked
angle is shifted right by the angle set
compensation angle
by the function code, while a
negative value indicates the
phase-locked angle is shifted left.
(Valid only for the six-pulse rectifier)
Bus voltage judgment hysteresis
upper limit V_ZH = Input voltage
(P08.06)*1.414 + P03.37;
When the actual bus voltage is
greater than V_ZH, the IGBT
feedback enabling angle starts to
increase slowly until it reaches 120
hysterisis degrees.
When the actual bus voltage is less
than V_ZL (see P28.05), the IGBT
feedback enabling angle starts to
decrease slowly until it reaches the
lower limit (see P03.38).
(Valid only for the six-pulse rectifier)
IGBT feedback During six-pulse rectifier mode, the
enabling angle feedback angle can be set through
Description
-27-
Goodrive3000 rectifier
Setting range Default
0.0–100.0% 90.0%
0.001–60.000 5.000
0.01–30.000 5.00
0–10 10
0–1
0–10 0.2
0–100 4
0.00–5.00 0
-30–+30 0
-800.0–300.0 30.0V
0–120 100°
