INVT Goodrive3000 Series Operation Manual page 185

Goodrive3000 series medium voltage VFD
Function
code
SM brake component
P13.17
enabling threshold voltage
SM brake component
P13.18
enabling time setting
P13.19–
P13.20
Start frequency of
P13.21 mal-adjustment fault
Mal-adjustment fault
P13.22
detection deviation angle
Enabling protection against
P13.23
P13.24–
P13.25
P14 group––Serial communication
Local communication
P14.00
P14.01 Communication baud rate
P14.02
Communication response
P14.03
P14.04 Communication timeout time 0.0 (invalid); 0.1–60.0s
Transmission error
P14.05
Communication processing
P14.06
Name
200.0–6000.0V
0.000–4.000s
Reserved
0.00–50.00Hz
determination
0.00–359.99°
0: Invalid
runaway fault 1: Valid
Reserved
1–247; 0 indicates a broadcast
address address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
6: 57600BPS
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
Data bit check
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
0–200ms
delay
0: Report an alarm and coast to
stop
1: Keep running without reporting
an alarm
2: Stop in enabled stop mode
without
processing
(applicable
communication mode)
3: Stop in enabled stop mode
without
(applicable to any mode)
0x00–0x11
action Ones place: Action upon the
Description
0.000–4.000
0.00–359.99
reporting an alarm
only to
reporting an alarm
-179-
Goodrive3000 inverter
Setting
Default Modify
range
200.0– Model
6000.0 depended
1.000s
0.00–50.00 5.00Hz
36.00°
0–1 0
1–247 1
0–6 4
0–5 1
0–200 5ms
0.0–60.0 0.0s
0–3 0
0x00–0x11 0x00
○
○
○
○
○
○
○
○
○
