11.3 Filters

We offer high-performance filters for selection.
The following table shows the filter selection for 1140V voltage grade (for other voltage grades, the selection is determined
according to the specific model).
Model
GD3000-01-055G-12
GD3000-11-055G-12
GD3000-01-075G-12
GD3000-11-075G-12
GD3000-01-090G-12
GD3000-11-090G-12
GD3000-01-110G-12
GD3000-11-110G-12
GD3000-01-132G-12
GD3000-11-132G-12
GD3000-01-160G-12
GD3000-11-160G-12
GD3000-01-200G-12
GD3000-11-200G-12
Input reactor
25006-00298
25006-00438
25006-00438
25006-00438
25006-00210
25006-00210
25006-00210
25006-00441
25006-00441
25006-00435
25006-00435
Input filter
FLT-P1250H-B
FLT-P1250H-B
FLT-P12100H-B
FLT-P12100H-B
FLT-P12100H-B
FLT-P12100H-B
FLT-P12200H-B
-237-
Optional peripheral accessories
Output reactor
25006-00395
25006-00072
25006-00072
25006-00072
25006-00431
25006-00431
25006-00431
25006-00440
25006-00440
25006-00434
25006-00434
Output filter
FLT-L1250H-B
FLT-L1250H-B
FLT-L12100H-B
FLT-L12100H-B
FLT-L12100H-B
FLT-L12200H-B
FLT-L12200H-B
