Goodrive3000 series medium voltage VFD
Click Send. If the line configuration and settings are correct, a response transmitted by the VFD is received

as follows.

8.5 Common communication faults

Common communication faults include the following:
No response is returned.

The VFD returns an exception response.

Possible causes of no response include the following:
The serial port is set incorrectly. For example, the adapter uses the serial port COM1, but COM2 is selected for the

communication.
The settings of the baud rates, data bits, end bits, and check bits are inconsistent with those set on the VFD.

The positive pole (+) and negative pole (-) of the RS485 bus are connected reversely.

The resistor connected to 485 terminals on the terminal block of the VFD is set incorrectly.


8.6 Related function codes

8.6.1 Related function codes for Goodrive3000 rectifier

Functio
n code
P11.00 communication
address
Communication
P11.01
baud rate
P11.02 Data bit check
Communication
P11.03
response delay
Communication
P11.04
timeout time
Transmission error
P11.05
processing
03 06
VFD
Write
address
command
Name
Local
1–247; 0 indicates a broadcast address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
0–200ms
0.0 (invalid); 0.1–60.0s
0: Report an alarm and coast to stop
1: Keep running without reporting an alarm
2: Stop in enabled stop mode without reporting an
alarm (applicable only to communication mode)
3: Stop in enabled stop mode without reporting an
alarm (applicable to any mode)
20 00 00 01
Parameter
Forward running
address
Description
-208-
Moudbus protocol
42 28
CRC
Setting
Default
range
1–247
0–5
0–5
0–200
0.0–60.0s 0.0s
0–3
1
4
1
5
0
