P12 Group--Parameters Of Motor 2 - INVT Goodrive3000 Series Operation Manual

Goodrive3000 series medium voltage VFD
Function
code
Overload calculation
P11.29
P11.30
P12 group––Parameters of motor 2
Function
code
P12.00
P12.01
P12.02
P12.03
P12.04
P12.05
P12.06
P12.07
P12.08 Leakage inductance of AM 2 0.1–6553.5mH
P12.09 Mutual inductance of AM 2
P12.10
coefficient 1 of iron core of AM
P12.11
coefficient 2 of iron core of AM
P12.12
P12.13 coefficient 3 of iron core of AM
P12.14 coefficient 4 of iron core of AM
P12.15
P12.16
P12.17 Number of pole pairs of SM 2 1–50
P12.18
Name
0: Traditional method
1: Integral method
method
Reserved
Name
Type of motor 2
Rated power of AM 2
Rated frequency of AM 2
Rated speed of AM 2
Rated voltage of AM 2
Rated current of AM 2
Stator resistance of AM 2
Rotor resistance of AM 2
No-load current of AM 2
Magnetic saturation
2
Magnetic saturation
2
Magnetic saturation
2
Magnetic saturation
2
Rated power of SM 2
Rated frequency of SM 2
Rated voltage of SM 2
Description
Description
0: Asynchronous motor (AM)
1: Reserved
0.1–3000.0kW
0.01Hz–P00.03 (Max. output
frequency)
1–36000rpm
0–4000V
0.8–6000.0A
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5A
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.1–3000.0kW
0.01Hz–P00.03 (Max. output
frequency)
0–4000V
-119-
Goodrive3000 inverter
Setting range Default
0–2 0
Setting range Default
0–1 0
Model
0.1–3000.0
depended
0.01–P00.03 50.00Hz
Model
1–36000
depended
Model
0–4000
depended
Model
0.8–6000.0
depended
Model
0.001–65.535Ω
depended
Model
0.001–65.535Ω
depended
Model
0.1–6553.5mH
depended
Model
0.1–6553.5mH
depended
Model
0.1–6553.5A
depended
0.0–100.0 80.0%
0.0–100.0 68.0%
0.0–100.0 57.0%
0.0–100.0 40.0%
Model
0.1–3000.0
depended
0.01–P00.03 50.00Hz
1–50 2
Model
0–4000
depended
