Goodrive3000 series medium voltage VFD
P22 group––Synchronous switchover
Function
code
Grid synchronization
P22.00
P22.01
Upper limit frequency
P22.02 of positive sequence
Angle compensation
P22.03
Upper limit frequency
P22.04 of negative sequence
Angle compensation
P22.05
P22.06 Phase-lock test mode
P22.07 Analog grid frequency -60.0–60.0Hz
P22.08
P22.09
synchronous output
P23 group––Storage function of communication SD card
Function code
P23.00
P23.01
P23.02
P23.03
P23.04
P23.05
P23.06
P23.07
Name
0: Common mode
mode selection 1: Grid synchronization mode
Power frequency
0: With reactor
mode switchover
1: Without reactor (Reserved)
selection
0.00–10.00Hz
adjustment
value of positive -180.0–180.0°
sequence phase
0.00–10.00Hz
adjustment
value of negative -180.0–180.0°
sequence phase
0: Invalid
1: Valid (The grid voltage input can be
simulated according to the setting value
of P22.07–P22.08, and the actual grid
input will be masked in the test mode.)
Simulated grid
0–6000.0V
voltage
Power/variable
0–16
frequency
The smaller the value, the faster the
synchronization speed.
filtering times
Name
0: Disable (Ethernet
Memory enabling communication)
1: Enable (SD card storage)
Year setting 0000–9999
Date setting 01.01–12.31
Time setting 00.00–23.59
Seconds setting 00–59
Recorded value of
half bus voltage 0–1000.0
deviation
Size of file 2 0–1024
0: Start upon power-on and stop
Data logging trigger
upon power-off
conditions
1: Start upon running and stop upon
Description
Description
-135-
Goodrive3000 inverter
Setting range Default
0–1 0
0–1 0
0.00–10.00 0.00Hz
-180.0–180.0 0.0°
0.00–10.00 0.00Hz
-180.0–180.0 0.0°
0–1 0
-60.0–60.0 0.00Hz
0–6000.0 0V
0–16 8
Setting range Default
0–1 1
0000–9999 2019
01.01–12.31 01.01
00.00–23.59 0.00
00–59 00
0–1000.0 200.0
0–1024 50
0–2 0
