Safety Precautions; Safety Definition; Warning Symbols; Safety Guidelines - INVT Goodrive3000 Series Operation Manual

Goodrive3000 series medium voltage VFD
Read this manual carefully and follow all safety precautions before moving, installing, operating and servicing the product.
Otherwise, equipment damage or physical injury or death may be caused.
We shall not be liable or responsible for any equipment damage or physical injury or death caused by you or your
customers due to your ignorance of the safety precautions.

1.1 Safety definition

In this manual, safety information is classified into:
Danger: Severe personal injury or even death can result if related requirements are not followed.
Warning: Personal injury or equipment damage can result if related requirements are not followed.
Note: Actions taken to ensure proper running.
Electrostatic sensitive: PCBA board or module damage can result if related requirements are not followed.
Trained and qualified professionals: People working on the VFD must have received professional electrical and safety
training and obtained the certificates, and must be familiar with all steps and requirements of VFD installing,
commissioning, running and maintaining and capable to prevent any emergencies.

1.2 Warning symbols

Warnings caution you about conditions that can result in severe injury or death and/or equipment damage and advice on
how to prevent dangers. The following table lists the warning symbols in this manual.
Symbol
Electrostatic sensitive
Note

1.3 Safety guidelines

1.3.1 Installation and maintenance








1 Safety precautions

Name
Severe personal injury or even death can result if related
Danger
requirements are not followed
Personal injury or equipment damage can result if related
Warning
requirements are not followed
PCBA board or module damage can result if related requirements
are not followed.
Note Actions taken to ensure proper running
Do not perform any live operation on the VFD, motor, or motor cables.
Only trained and qualified professionals can operate the VFD.
When you need to maintain the VFD, motor, or motor cable, do as follows before the
maintenance: Check the power indicator first, wait for 25 minutes after the power
indicator is turned off, and then confirm that the internal bus capacitance of the VFD
has been discharged. To check whether the discharge is completed, you can use a
multimeter and an attenuation probe to measure whether the voltage between the VFD
bus terminals (+) and (-) is below 36V.
Do not have live contact with the VFD control part or the external circuit connected to
the VFD control part, because the external control circuit may cause dangerous voltage
to be generated inside the VFD even if the VFD is powered off.
Do not perform the insulation withstand voltage test on the VFD as our products has
already been tested for voltage withstand at the factory.
When the motor needs to be re-connected, check whether the motor cable phase
sequence is correct.
Description
-1-
Safety precautions
