INVT Goodrive3000 Series Operation Manual page 212

Goodrive3000 series medium voltage VFD
01
address
Assume that the following response is returned:
The data content returned by the VFD is 0003H, which indicates that the VFD is in the stopped state.
Example 2: View information about the VFD whose address is 03H, including "Present fault type" (P07.27) to "5th-last
fault type" (P07.32) of which the parameter addresses are 071BH to 0720H (contiguous 6 parameter addresses starting
from 071BH).
The command transmitted to the VFD is as follows:
Assume that the following response is returned:
03 03 0C 00 23 00 23 00 23 00 23
VFD Read
address command
From the returned data, we can see that all the fault types are 0023H, that is, 35 in the decimal form, which means the
maladjustment fault (STo).
8.4.7.2 Example of writing command 06H
Example 1: Set the VFD whose address is 03H to be forward running. Refer to the table of other function parameters, the
address of "Communication-based control command" is 2000H, and 0001H indicates forward running, as shown in the
following table.
Function
Communication-base
d control command
The command transmitted from the master is as follows:
If the operation is successful, the following response is returned (same as the command sent from the master):
address
03
VFD
Read
command
01 03
VFD
Read
address
command
03 03
VFD
Read
address
command
Number of Most recent
Last fault
bytes fault type
type
Address
0001H: Run forward
0002H: Run reversely
0003H: Jog forward
0004H: Jog reversely
2000H 0005H: Stop
0006H: Coast to stop (in emergency)
0007H: Fault reset
0008H: Jogging stop
0009H: Pre-exciting
03 06
VFD
Write
address
command
03 06
VFD
Write
command
21 00 00 01
Parameter
Data quantity
address
02 00 03
Number
Data content
of bytes
07 1B 00 06
Start
6 parameters in total
address
2nd-last fault 3rd-last fault
type type
Data description
20 00 00 01
Parameter Forward
address
running
20 00 00 01
Parameter
Forward
address running
-206-
8E 36
CRC
F8 45
CRC
B5 59
CRC
00 23 00 23 5F D2
4th-last fault 5th-last fault
type type
42 28
CRC
42 28
CRC
Moudbus protocol
CRC
R/W
W
