Goodrive3000 series medium voltage VFD
Function
code
P06.16 RO3 switch-off delay
P06.17
P06.18
P06.19
HDO high-speed pulse
P06.20
P06.21 AO1 output lower limit
AO1 output corresponding to
P06.22
P06.23 AO1 output upper limit
AO1 output corresponding to
P06.24
P06.25 AO1 output filter time
Name
0.000–50.000s
AO1 output 0: Running frequency
1: Set frequency
AO2 output
2: Ramp reference frequency
AO3 output
3: Rotational speed
4: Output current (relative to the
VFD)
5: Output current (relative to the
motor)
6: Output voltage
7: Output power
8: Set torque
9: Output torque
10: AI1 input
11: AI2 input
12: AI3 input
13: High-speed pulse HDI input
14: Value 1 set through
MODBUS communication
15: Value 2 set through
MODBUS communication
16: Value 1 set through
output
PROFIBUS/CANopen
communication
17: Value 2 set through
PROFIBUS/CANopen
communication
18: Value 1 set through Ethernet
communication
19: Value 2 set through Ethernet
communication
20: PID reference
21: PID feedback
22: Torque current (relative to
the motor rated current)
23: Ramp reference frequency
(signed)
24–30: Reserved
-100.0%–P06.23
-10.00V–10.00V
lower limit
P06.21–100.0%
-10.00V–10.00V
upper limit
0.000s–10.000s
Description
-161-
Goodrive3000 inverter
Setting
Default Modify
range
0.00–50.00 0.000s
0–30 0
0–30 0
0–30 0
0–30 0
-100.0–
0.0%
P06.23
-10.00–
0.00V
10.00
P06.21–
100.0%
100.0
-10.00–
10.00V
10.00
0.000–
0.000s
10.000
○
○
○
○
○
○
○
○
○
