INVT Goodrive3000 Series Operation Manual page 62

Goodrive3000 series medium voltage VFD
Function
code
P11.01 Communication baud rate
P11.02 Data bit check
Communication response
P11.03
Communication timeout
P11.04
Transmission error
P11.05
Communication
P11.06
processing action
P11.07–
P11.08
CANopen communication
P11.09
CANopen communication
P11.10
CANopen communication
P11.11
CANopen communication
P11.12
Name
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
0–200ms
delay
0.0 (invalid); 0.1–60.0s
time
0: Report an alarm and coast to stop
1: Keep running without reporting an
alarm
2: Stop in enabled stop mode
without reporting an alarm
processing (applicable only to communication
mode)
3: Stop in enabled stop mode
without reporting an alarm
(applicable to any mode)
0x00–0x11
Ones place:
0: Respond to write operations
1: Not respond to write operations
Tens place:
0: Reserved
1: Reserved
Reserved
0–127
address
0: 50K BPS
1: 125K BPS
2: 250K BPS
baud rate
3: 500K BPS
4: 1M BPS
0.0 (invalid); 0.1–100.0s
fault delay
0: Common control protocol
1: Internal master/salve
protocol
communication protocol
Description
-56-
Goodrive3000 rectifier
Setting
Default Modify
range
0–5 4
0–5 1
0–200 5ms
0.0–60.0 0.0s
0–3 0
0x00–0x11 0x00
0–127 1
0–4 3
0.1–100.0 0.0s
0–1 0
○
○
○
○
◎
◎
◎
◎
◎
◎
