Goodrive3000 series medium voltage VFD
Please remember your password and save it in a secure place.
After you exit the function code editing interface, the password protection function is enabled within 1 minute. If password
protection is enabled, "0.0.0.0.0" is displayed when you press the PRG/ESC key again to enter the function code editing
interface. You need to enter the correct user password to enter the interface.
Note: Restoring the default values may delete the user password. Exercise caution when using this function.
Function
code
P07.01
The function code is used to set the parameter copy mode.
Note: After the operation corresponding to 1 or 2 is complete, the function code restores to 0.
Function
code
P07.02
The function code is used to set the function of the QUICK/JOG key.
Function
code
Stop function validity
P07.04
The function code is used to specify the stop function validity of STOP/RST. For fault reset, STOP/RST is valid in any
conditions.
Function
code
P07.05
There are 15 parameters that can be displayed in operation and stopping state: DC bus voltage (V), grid frequency (Hz),
input voltage (V), input current (A), input power factor (%), active current component (%), reactive current component (%),
input terminal state, output terminal state, AI1 (V), AI2 (V), AI3 (V), input apparent power (kVA), input active power (kW)
and input reactive power (kVar).
This function code determines parameter display. The value is a 16-bit binary number. If a bit is 1, the parameter
corresponding to this bit can be viewed through >>/SHIFT during running. If this bit is 0, the parameter corresponding to
this bit is not displayed. The content is shown in the following table.
Name
0: No operation
1: Upload parameters from the local
Parameter copy address to the keypad
2: Download parameters from the
keypad to the local address
Name
0: No function
1: Switch displayed function codes
from
Function of QUICK/JOG to shift the displayed
QUICK/JOG function code from right to left.
2: Reserved
3: Quick commissioning mode (based
on non-factory parameter settings)
Name
0: Valid only for keypad control
1: Valid both for keypad and terminal
control
of STOP/RST 2:
communication control
3: Valid for all control modes
Name
Parameter selection in
rectification state
Description
Description
right to left by
Description
Valid both for keypad
Description
0x0000–0xFFFF
-33-
Goodrive3000 rectifier
Setting range
0–2
Setting range
Press
0–3
Setting range
0–3
and
Setting range
0x0000–0xFFFF
Default
0
Default
0
Default
3
Default
0x000F
