INVT Goodrive3000 Series Operation Manual page 63

Goodrive3000 series medium voltage VFD
Function
code
P11.13–
P11.16
P12 group––PROFIBUS communication
P12.00
P12.01 Module address
P12.02 Received PZD2
P12.03 Received PZD3
P12.04 Received PZD4
P12.05 Received PZD5
P12.06 Received PZD6
P12.07 Received PZD7
P12.08 Received PZD8
P12.09 Received PZD9
P12.10 Received PZD10
P12.11 Received PZD11
P12.12 Received PZD12
P12.13
P12.14
P12.15
P12.16
P12.17
P12.18
P12.19
P12.20
P12.21
P12.22
P12.23
Temporary variable 1 for
P12.24
DP communication
P12.25
P12.26–
P12.29
Name
Reserved
Module type 0: PROFIBUS
0–127
0: Disable
1: DC voltage setting (0–60000;
Unit: 0.1V)
2–4: Reserved
5: AO setting 1
(-1000–1000, 1000 corresponding
to 100.0%)
6: AO setting 2
(-1000–1000, 1000 corresponding
to 100.0%)
7–13: Reserved
0: Disable
Sent PZD2
1: DC voltage (* 10, V)
Sent PZD3
2: DC voltage feedback (* 10, V)
Sent PZD4
3: Input voltage valid value (* 10, V)
Sent PZD5
4: Input current valid value (* 10, A)
Sent PZD6
5: Input power (* 10, kW)
Sent PZD7
6: Input power factor (*100)
Sent PZD8
7: Grid frequency (* 10, Hz)
Sent PZD9
8: Active current feedback (100%
Sent PZD10 corresponds to the rectifier rated
current.)
Sent PZD11
9: Reactive current feedback (100%
corresponds to the rectifier rated
current.)
10: Fault code
11: AI1 input (*100, V)
12: AI2 input (*100, V)
Sent PZD12
13: AI3 input (* 100, V)
14: Terminal input status
15: Terminal output status
16: Running status word
17–20: Reserved
0–65535
PZD sending
0.0 (invalid), 0.1–60.0s
timeout time
Reserved
Description
-57-
Goodrive3000 rectifier
Setting
Default Modify
range
0 0
0–127 2
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–65535 0
0.0–60.0 0.0s
●
●
◎
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
●
