INVT Goodrive3000 Series Operation Manual page 176

Goodrive3000 series medium voltage VFD
Function
code
P08.42 Keypad digit control setting
Keypad digital potentiometer
P08.43
UP/DOWN terminal control
P08.44
Name
1: Enable
0x0000–0x1223
Ones place: Frequency setting
selection
0: Controls through both the ∧/
∨ key and digital potentiometer
are valid.
1: Only control through the ∧/∨
key is valid.
2: Only control through the digital
potentiometer is valid.
3: Controls through the ∧ / ∨
key and digital potentiometer are
invalid.
Tens place: Frequency control
selection
0: Valid only when P00.06=0 or
P00.07=0
1: Valid for all frequency setting
methods
Hundreds place: Action selection
for stop
0: Setting is valid.
1: Valid during running, cleared
after stop
2: Valid during running, cleared
after a stop command is received
Thousands
function of the ∧ / ∨ key and
digital potentiometer
0: Enable the integral function
1: Disable the integral function
0.01–10.00s
integral time
0x000–0x221
Ones place: Frequency setting
selection
0: The setting made through
UP/DOWN is valid.
1: The setting made through
UP/DOWN is invalid.
setting Tens place: Frequency control
selection
0: Valid only when P00.06=0 or
P00.07=0
1: Valid for all frequency setting
methods
Hundreds place: Action selection
Description
place: Integral
0x000–
0x221
-170-
Goodrive3000 inverter
Setting
Default Modify
range
0x0000–
0x0000
0x1223
0.01–10.00 0.10s
0x000
○
○
○
