INVT Goodrive3000 Series Operation Manual page 97

Goodrive3000 series medium voltage VFD
Setting
26
27–28
29 Motor OH pre-alarm
30 synchronous output at
Function
code
P06.06
The function code is used to set the polarity of output terminals.
When a bit is 0, the output terminal is positive; when a bit is 1, the output terminal is negative.
BIT5
Reserved
Functio
n code
P06.07 Y switch-on delay
P06.08 Y switch-off delay
P06.09 HDO switch-on delay
P06.10 HDO switch-off delay
P06.11 RO1 switch-on delay
P06.12 RO1 switch-off delay
P06.13 RO2 switch-on delay
P06.14 RO2 switch-off delay
P06.15 RO3 switch-on delay
P06.16 RO3 switch-off delay
The function codes specify the delay time corresponding to the electrical level changes when the programmable output
terminals switch on or switch off.
Function
code
P06.17
P06.18
P06.19
P06.20
Function
the value is 0, the OFF signal is output.
DC bus voltage Output is valid when the bus voltage exceeds the undervoltage
established threshold.
Reserved
The signal is valid when the temperature of the motor is larger than
the set pre-alarm temperature and less than motor overheat
protection point.
Phase-locked and When this terminal is valid and P22.00 is set to 1, the running
command performs the switchover from variable frequency to
power frequency power frequency.
Name
Output terminal
0x00–0x1F
polarity selection
BIT4
RO3
Name
0.000–50.000s
0.000–50.000s
0.000–50.000s (valid when P06.00 is 1) 0.000–50.000
0.000–50.000s (valid when P06.00 is 1) 0.000–50.000
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
Y electric level
Y valid
Name
AO1 output
0: Running frequency
1: Set frequency
AO2 output
2: Ramp reference frequency
3: Rotational speed
AO3 output
4: Output current (relative to the VFD)
HDO high-speed
Description
BIT3 BIT2
RO2 RO1
Description
Invalid Valid
Switch on
delay
Description
-91-
Description
Setting range
0x00–0x1F
BIT1
Y1
Setting range
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.00–50.00
0.00–50.00
invalid
Switch off
delay
Setting range
0–30
0–30
0–30
Goodrive3000 inverter
Default
0x00
BIT0
HDO
Default
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
Default
0
0
0
