INVT Goodrive3000 Series Operation Manual page 41

Goodrive3000 series medium voltage VFD
Function
code
P08.00 Rectifier rated power
P08.01 Rectifier rated current
P08.04
P08.05
P08.06
P08.07
P08.08
P08.09
P08.10
Digital input terminal
P08.11
Digital output terminal
P08.12
P08.13
P08.14
P08.15
P08.16 Input apparent power
P08.17 Input active power
P08.18 Input reactive power
P08.19
Name
Displays the rectifier rated power.
0–6000kW
Displays the rectifier rated current.
0.0–6000.0A
Displays the DC voltage of the rectifier.
DC voltage
0.0–6000.0V
Displays the grid frequency.
Grid frequency
0.00–120.0Hz
Displays the grid voltage.
Grid voltage
0.0–4000.0V
Displays the grid input current.
Grid input current
0.0–6000.0A
Displays the power factor of the
Power factor rectifier.
-1.00–1.00
Displays the active current percentage
Active current
of the rectifier.
percentage
-200.0–200.0%
Displays the reactive current
Reactive current
percentage of the rectifier. -200.0–
percentage
200.0%
0x0–0xF
Bit 0 corresponds to S1
status Displays the present digital input
terminal status.
0x0–0xF
Bit 0 corresponds to RO1
status Displays the present digital output
terminal status.
Displays the AI1 input signal.
AI1 input voltage
0.00–10.00V
Displays the AI2 input signal.
AI2 input voltage
-10.00–10.00V
Displays the AI3 input signal.
AI3 input voltage
0.00–10.00V
Displays the input apparent power of
the rectifier.
0–6000.0kVA
Displays the input active power of the
rectifier.
0–6000.0kW
Displays the input reactive power of the
rectifier.
0–6000.0kVar
Displays
3PH voltage unbalance factor of the rectifier.
unbalance factor It is the ratio of the maximum value of
rectifier input voltage to the minimum
Description
the three-phase voltage
-35-
Goodrive3000 rectifier
Setting range Default
Model
0–6000.0
depended
Model
0.0–6000.0
depended
0.0–6000.0 0.0V
0.00–120.0 0.0Hz
0.0–4000.0 0.0V
0.0–6000.0 0.0A
-1.00–1.00 0.00
-200.0–200.0 0.0%
-200.0–200.0 0.0%
0x0–0xF 0x0
0x0–0xF 0x0
0.00–10.00 0.00V
-10.00–10.00 0.00V
0.00–10.00 0.00V
0–6000.0 0.0kVA
0–6000.0 0.0kW
0–6000.0 0.0kVar
1.00–10.00 0.00
