INVT Goodrive3000 Series Operation Manual page 76

Goodrive3000 series medium voltage VFD
Function
code
Rated voltage of AM
P02.04
P02.05 Rated current of AM 1 0.8–6000.0A
The function codes are used to set the parameters for the controlled AM.
To ensure the control performance, set P02.01–P02.05 correctly according to the information on the nameplate of the AM.
The VFD provides the parameter autotuning function. Whether parameter autotuning can be performed properly depends
on the settings of the motor nameplate parameters.
In addition, you need to configure a motor according to the standard motor configuration of the VFD. If the power of the
motor is greatly different from that of the standard motor configuration, the control performance of the VFD degrades
significantly.
Note: Resetting the rated power of the motor (P02.01) can initialize the parameters P02.02–P02.10.
Function
code
Stator resistance of
P02.06
Rotor resistance of
P02.07
Leakage inductance
P02.08
Mutual inductance of
P02.09
No-load current of
P02.10
Note: Do not modify these parameters unless it is necessary.
After motor parameter autotuning is properly performed, the values of P02.06–P02.10 are automatically updated. These
parameters are the benchmark parameters for high-performance vector control, directly affecting the control performance.
Function
code
Magnetic saturation
P02.11 coefficient 1 of iron
Magnetic saturation
coefficient 2 of iron
P02.12
Magnetic saturation
coefficient 3 of iron
P02.13
Magnetic saturation
P02.14 coefficient 4 of iron
The function codes indicate the magnetic saturation coefficients of AM in flux-weakening control.
Function
code
P02.15 Rated power of SM 1 0.1–3000.0kW
Name
0–4000V
1
Name
0.001–65.535Ω
AM 1
0.001–65.535Ω
AM 1
0.1–6553.5mH
of AM 1
0.1–6553.5mH
AM 1
0.1–6553.5A
AM 1
Name
0.0–100.0%
core of AM 1
0.0–100.0%
core of AM 1
0.0–100.0%
core of AM 1
0.0–100.0%
core of AM 1
Name
Description
Description
Description
Description
-70-
Goodrive3000 inverter
Setting range Default
Model
0–4000
depended
Model
0.8–6000.0
depended
Setting range Default
Model
0.001–65.535
depended
Model
0.001–65.535
depended
Model
0.1–6553.5
depended
Model
0.1–6553.5
depended
Model
0.1–6553.5
depended
Setting range Default
0.0–100.0 80.0%
0.0–100.0 68.0%
0.0–100.0 57.0%
0.0–100.0 40.0%
Setting range Default
Model
0.1–3000.0
depended
