Sin Three-wire control; FWD: Forward running; REV: Reverse running
Note: For two-wire controlled running mode, when the FWD/REV terminal is valid, if the VFD stops due to a stop
command given by another source, the VFD does not run again after the stop command disappears even if the
control terminal FWD/REV is still valid. To make the VFD run, you need to trigger FWD/REV again, for example,
PLC single-cycle stop, fixed-length stop, and valid STOP/RST stop during terminal control. (See P07.04.)
Function
code
P05.14
P05.15
P05.16
P05.17
P05.18
P05.19
P05.20
P05.21
P05.22
P05.23
P05.24
P05.25
P05.26
P05.27
P05.28
P05.29
P05.30
P05.31
Used to specify the delay time corresponding to the electrical level changes when the programmable input terminals
switch on or switch off.
Function
code
P05.32
Corresponding setting of
P05.33
P05.34
Corresponding setting of
P05.35
P05.36
P05.37
Corresponding setting of
P05.38
P05.39
Corresponding setting of
P05.40
P05.41
Name
S1 switch-on delay 0.000–50.000s
S1 switch-off delay 0.000–50.000s
S2 switch-on delay 0.000–50.000s
S2 switch-off delay 0.000–50.000s
S3 switch-on delay 0.000–50.000s
S3 switch-off delay 0.000–50.000s
S4 switch-on delay 0.000–50.000s
S4 switch-off delay 0.000–50.000s
S5 switch-on delay 0.000–50.000s
S5 switch-off delay 0.000–50.000s
S6 switch-on delay 0.000–50.000s
S6 switch-off delay 0.000–50.000s
S7 switch-on delay 0.000–50.000s
S7 switch-off delay 0.000–50.000s
S8 switch-on delay 0.000–50.000s
S8 switch-off delay 0.000–50.000s
HDI switch-on delay 0.000–50.000s
HDI switch-off delay 0.000–50.000s
Si electrical level
Si valid invalid
Name
AI1 lower limit 0.00V–P05.34
-100.0%–100.0%
AI1 lower limit
AI1 upper limit P05.32–10.00V
-100.0%–100.0%
AI1 upper limit
AI1 input filter time 0.000s–10.000s
AI2 lower limit -10.00V–P05.39
-100.0%–100.0%
AI2 lower limit
AI2 middle value P05.37–P05.41
-100.0%–100.0%
AI2 middle value
AI2 upper limit P05.39–10.00V
Description
valid
Switch-on Switch-off
delay
delay
Description
-87-
Goodrive3000 inverter
Setting range
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
invalid
Setting range
0.00–P05.34
-100.0–100.0
P05.32–10.00
-100.0–100.0
0.000–10.000
-10.00V–P05.39
-100.0–100.0
P05.37–P05.41
-100.0–100.0
P05.39–10.00
Default
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
Default
0.00V
0.0%
10.00V
100.0%
0.100s
0.00V
0.0%
0.00V
0.0%
10.00V
