P11 group Protection parameters

Function
Name
code
Phase loss
P11.00
protection
Frequency-
P11.01 drop at sudden
power dip
Frequency-
drop ratio at
P11.02
sudden power
dip
1: Minutes; the running time of all stages is
counted by minute
0x00–0x11
Ones place:
0: Input phase loss software protection disable
1: Input phase loss software protection enable
Tens place:
0: Output phase loss protection disable
1: Output phase loss protection enable
Hundreds place:
0: Input phase loss hardware protection disable
1: Input phase loss hardware protection enable
0: Disable
1: Enable
Setting range: 0.00Hz/s–P00.03 (the max.
frequency)
After the power loss of the grid, the bus voltage
drops to the sudden frequency-decreasing point,
the VFD begin to decrease the running
frequency at P11.02, to make the VFD generate
power again. The returning power can maintain
the bus voltage to ensure a rated running of the
VFD until the recovery of power.
Voltage 220/
degree 230V
Frequency
decrease
point at 240V 460V
sudden
power loss
Note:
 Adjust the parameter properly to avoid the
stopping caused by VFD protection during the
Description
Description
400V 460V
530V
-91-
Function parameters
Default Modify
Default Modify
0x10
0
10.00
660V Hz/s
800V
○
○
○
