Model 493.40 I/O Carrier Connections - MTS Systems FlexTest IIm Manual

C D
ABLE ESCRIPTION
Interlock—Station
Remote Station Control—with E-Stop
Remote Station Control—with Station Stop
Workstation Link (Ethernet cable)
Remote Setpoint Adjust Control
* -XX specifies cable length. –01 through –09 represent 10–50 ft. in 5 ft. increments. Higher numbers
represent custom cable lengths
† Jumper plugs are required if a cable is not installed.
‡ The connector is the 10/100 BaseT connector on the power PC module.

Model 493.40 I/O Carrier Connections

MTS 793 Controller Hardware
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
System Cables (part 2 of 2)
.
Each Model 493.40 I/O Carrier module can include up to four
mezzanine cards. Each installed mezzanine card is assigned a specific
I/O Carrier module front panel connector (J4–J7 I/O).
A hardware interface file (hwi) defines each type of module (and their
associated mezzanine cards) and maps each module location for the
system software. The hwi file and the physical locations for each type
of module and associated mezzanine cards must match. Also, the I/O
Carrier module address setting (on the module) must match the hwi
file address. For more information on the hwi file, see the MTS 793
Utility Software manual.
• Transducer connections require a conditioner mezzanine card to
be installed in the I/O Carrier module. The following conditioners
can be installed:
– Model 493.21B Digital Universal Conditioner
– Model 493.25 Digital Universal Conditioner
– Model 493.47 Encoder
– Model 493.48 Acceleration Conditioner
P M
ART ODULE
C
UMBER *
ONNECTOR
N
per system 493.74 J43
055-634-2XX 493.71 J50
055-634-3XX 493.71 J50
051-996-8XX
‡
10/100
100-051-058 493.40 J4–J7
FlexTest GT Controller Connections
J
UMPER
LUG †
P
100-007-948
055-634-101
055-634-101
N/A
N/A
77
