Single-Valve Connection; Dual-Valve Connection - MTS Systems FlexTest IIm Manual

Single-valve
connection
Dual-valve
connection
164
FlexTest IIm Controller Connections
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
+ Valve
9
Command 1
– Valve
11
Command 1
Shown for valves phased the
same hydraulically. For valves
phased opposite hydraulically,
reverse A and D on P2.
P0
+ Valve
9
Command 1
– Valve
11
Command 1
A
B
C
D
P2
A
B
C
D
P1
A
B
C
D
MTS 793 Controller Hardware
